Switch to dark mode inside tunnels

In this example, we illustrate how to modify the map display (between light and dark modes) based on the location within a specific route.

To mimic the movement of a vehicle, we employ an animated point along the route. In this scenario, we simulate the vehicle entering a tunnel, prompting a switch to the dark map style. Subsequently, when the vehicle exits the tunnel, we revert back to the light map style. You can download the vehicle image, and obtain the route geoJSON file.


npm install --save @maptiler/sdk @turf/turf

main.js

import { Map, MapStyle, config } from '@maptiler/sdk';
import '@maptiler/sdk/dist/maptiler-sdk.css';
import * as turf from '@turf/turf';

config.apiKey = 'YOUR_MAPTILER_API_KEY_HERE';
let activeMode = "light";
let route;
// Used to increment the value of the point measurement against the route.
let counter = 0;
const style = getStyleByMode(activeMode);
const map = new Map({
  container: 'map',
  style: MapStyle.STREETS.LIGHT,
  center: [6.7979, 45.8515],
  zoom: 10,
  hash: true
});

function getStyleByMode(mode) {
  return (mode == 'dark') ? MapStyle.STREETS.DARK : MapStyle.STREETS.LIGHT;
}

function switchMode(mode) {
  stop();
  activeMode = mode;
  const style = getStyleByMode(mode);
  map.setStyle(style);
}

function tunnelEntrance(counter) {
  return counter == 779;
}

function tunnelExit(counter) {
  return counter == 1131;
}

let playing = true;

const origin = [6.856344820704434, 45.90164121615423];
// A single point that animates along the route.
// Coordinates are initially set to origin.
const point = {
  'type': 'FeatureCollection',
  'features': [
    {
      'type': 'Feature',
      'properties': {},
      'geometry': {
        'type': 'Point',
        'coordinates': origin
      }
    }
  ]
};

// Number of steps to use in the animation, more steps means
// a smoother animation, but too many steps will result in a
// low frame rate
const steps = 1500;

//load the route GeoJSON form MapTiler Cloud
maptilersdk.data.get('YOUR_MAPTILER_DATASET_ID_HERE')
.then((data) => {
  route = data;

  const options = {tolerance: 0.0001, highQuality: true};
  route = turf.simplify(route, options);

  // Calculate the distance in kilometers between route start/end point.
  const lineDistance = turf.length(route.features[0], 'kilometers');

  const arc = [];

  // Draw an arc between the `origin` & `destination` of the two points
  for (let i = 0; i < lineDistance; i += lineDistance / steps) {
      const segment = turf.along(route.features[0], i, 'kilometers');
      arc.push(segment.geometry.coordinates);
  }

  // Update the route with calculated arc coordinates
  route.features[0].geometry.coordinates = arc;

  map.on('load', function () {

    loadAnimationLayers();

    counter = 0;
    // Start the animation.
    animate(counter);
  });

  map.on('styledata', () => {
    const waiting = () => {
      if (!map.isStyleLoaded()) {
        setTimeout(waiting, 100);
      } else {
        loadAnimationLayers();
      }
    };
    waiting();
  });

});

async function loadAnimationLayers() {
  if (!map.hasImage('cat')) {
    const image = await map.loadImage('../navigation.png');
    map.addImage('cat', image.data);
  }

  // Add a source and layer displaying a point which will be animated in a circle.
  if (!map.getSource('route')) {
    map.addSource('route', {
      'type': 'geojson',
      'data': route
    });

    map.addSource('point', {
      'type': 'geojson',
      'data': point
    });
  }

  if (!map.getLayer('route')) {
    map.addLayer({
      'id': 'route',
      'source': 'route',
      'type': 'line',
      'paint': {
          'line-width': 2,
          'line-color': '#007cbf'
      }
    });

    map.addLayer({
      'id': 'point',
      'source': 'point',
      'type': 'symbol',
      'layout': {
        'icon-image': 'cat',
        'icon-size': 0.05,
        'icon-rotate': ['get', 'bearing'],
        'icon-rotation-alignment': 'map',
        'icon-overlap': 'always',
        'icon-ignore-placement': true
      }
    });

    playing = true;
    // Restart the animation.
    animate(counter);
  }
}

function stop() {
  playing = false;
}

function animate() {
  if (!playing) return;
  // Update point geometry to a new position based on counter denoting
  // the index to access the arc.
  point.features[0].geometry.coordinates =
    route.features[0].geometry.coordinates[counter];

  // Calculate the bearing to ensure the icon is rotated to match the route arc
  // The bearing is calculate between the current point and the next point, except
  // at the end of the arc use the previous point and the current point
  try {
    point.features[0].properties.bearing = turf.bearing(
      turf.point(
        route.features[0].geometry.coordinates[
          counter >= steps ? counter - 1 : counter
        ]
      ),
      turf.point(
        route.features[0].geometry.coordinates[
          counter >= steps ? counter : counter + 1
        ]
      )
    );
  } catch (error) {

  }

  // Update the source with this new data.
  map.getSource('point').setData(point);

  // Request the next frame of animation so long the end has not been reached.
  if (counter < steps - 1) {
    requestAnimationFrame(animate);
  }

  counter = counter + 1;

  if (tunnelEntrance(counter)) {
    switchMode('dark');
  } else if (tunnelExit(counter)) {
    switchMode('light');
  }
}

document.getElementById('replay').addEventListener('click', function () {
  // Set the coordinates of the original point back to origin
  point.features[0].geometry.coordinates = origin;

  // Update the source layer
  map.getSource('point').setData(point);

  // Reset the counter
  counter = 0;

  // Restart the animation.
  animate(counter);
});

index.html

<!DOCTYPE html>
<html lang="en">
<head>
  <meta charset="UTF-8">
  <meta name="robots" content="noindex">
  <title>How to change the style (light/dark) of the map based on the position in a route</title>
  <link rel="stylesheet" href="./style.css">
</head>
<body>
  <div id="map"></div>
  <div class="overlay">
  <button id="replay">Replay</button>
  </div>
  <script type="module" src="./main.js"></script>
</body>
</html>

style.css

body { margin: 0; padding: 0; }
	#map { position: absolute; top: 0; bottom: 0; width: 100%; }
.overlay {
  position: absolute;
  top: 10px;
  left: 10px;
}

.overlay button {
  font: 600 12px/20px 'Helvetica Neue', Arial, Helvetica, sans-serif;
  background-color: #3386c0;
  color: #fff;
  display: inline-block;
  margin: 0;
  padding: 10px 20px;
  border: none;
  cursor: pointer;
  border-radius: 3px;
}

.overlay button:hover {
  background-color: #4ea0da;
}

<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8" />
<title>How to change the style (light/dark) of the map based on the position in a route</title>
<meta name="viewport" content="initial-scale=1,maximum-scale=1,user-scalable=no" />
<script src="https://cdn.maptiler.com/maptiler-sdk-js/v4.1.0/maptiler-sdk.umd.min.js"></script>
<link href="https://cdn.maptiler.com/maptiler-sdk-js/v4.1.0/maptiler-sdk.css" rel="stylesheet" />
<script src="https://cdn.jsdelivr.net/npm/@turf/turf@7/turf.min.js"></script>
<style>
	body { margin: 0; padding: 0; }
	#map { position: absolute; top: 0; bottom: 0; width: 100%; }
  .overlay {
    position: absolute;
    top: 10px;
    left: 10px;
  }

  .overlay button {
    font: 600 12px/20px 'Helvetica Neue', Arial, Helvetica, sans-serif;
    background-color: #3386c0;
    color: #fff;
    display: inline-block;
    margin: 0;
    padding: 10px 20px;
    border: none;
    cursor: pointer;
    border-radius: 3px;
  }

  .overlay button:hover {
    background-color: #4ea0da;
  }
</style>
</head>
<body>
<div id="map"></div>
<div class="overlay">
    <button id="replay">Replay</button>
</div>

<script>
    maptilersdk.config.apiKey = 'YOUR_MAPTILER_API_KEY_HERE';
    let activeMode = "light";
    let route;
    // Used to increment the value of the point measurement against the route.
    let counter = 0;
    const style = getStyleByMode(activeMode);
    const map = new maptilersdk.Map({
      container: 'map',
      style: maptilersdk.MapStyle.STREETS.LIGHT,
      center: [6.7979, 45.8515],
      zoom: 10,
      hash: true
    });

    function getStyleByMode(mode) {
      return (mode == 'dark') ? maptilersdk.MapStyle.STREETS.DARK : maptilersdk.MapStyle.STREETS.LIGHT;
    }

    function switchMode(mode) {
      stop();
      activeMode = mode;
      const style = getStyleByMode(mode);
      map.setStyle(style);
    }

    function tunnelEntrance(counter) {
      return counter == 779;
    }

    function tunnelExit(counter) {
      return counter == 1131;
    }

    let playing = true;

    const origin = [6.856344820704434, 45.90164121615423];
    // A single point that animates along the route.
    // Coordinates are initially set to origin.
    const point = {
      'type': 'FeatureCollection',
      'features': [
        {
          'type': 'Feature',
          'properties': {},
          'geometry': {
            'type': 'Point',
            'coordinates': origin
          }
        }
      ]
    };

    // Number of steps to use in the animation, more steps means
    // a smoother animation, but too many steps will result in a
    // low frame rate
    const steps = 1500;

    //load the route GeoJSON form MapTiler Cloud
    maptilersdk.data.get('YOUR_MAPTILER_DATASET_ID_HERE')
    .then((data) => {
      route = data;

      const options = {tolerance: 0.0001, highQuality: true};
      route = turf.simplify(route, options);

      // Calculate the distance in kilometers between route start/end point.
      const lineDistance = turf.length(route.features[0], 'kilometers');

      const arc = [];

      // Draw an arc between the `origin` & `destination` of the two points
      for (let i = 0; i < lineDistance; i += lineDistance / steps) {
          const segment = turf.along(route.features[0], i, 'kilometers');
          arc.push(segment.geometry.coordinates);
      }

      // Update the route with calculated arc coordinates
      route.features[0].geometry.coordinates = arc;

      map.on('load', function () {

        loadAnimationLayers();

        counter = 0;
        // Start the animation.
        animate(counter);
      });

      map.on('styledata', () => {
        const waiting = () => {
          if (!map.isStyleLoaded()) {
            setTimeout(waiting, 100);
          } else {
            loadAnimationLayers();
          }
        };
        waiting();
      });

    });

    async function loadAnimationLayers() {
      if (!map.hasImage('cat')) {
        const image = await map.loadImage('../navigation.png');
        map.addImage('cat', image.data);
      }

      // Add a source and layer displaying a point which will be animated in a circle.
      if (!map.getSource('route')) {
        map.addSource('route', {
          'type': 'geojson',
          'data': route
        });

        map.addSource('point', {
          'type': 'geojson',
          'data': point
        });
      }

      if (!map.getLayer('route')) {
        map.addLayer({
          'id': 'route',
          'source': 'route',
          'type': 'line',
          'paint': {
              'line-width': 2,
              'line-color': '#007cbf'
          }
        });

        map.addLayer({
          'id': 'point',
          'source': 'point',
          'type': 'symbol',
          'layout': {
            'icon-image': 'cat',
            'icon-size': 0.05,
            'icon-rotate': ['get', 'bearing'],
            'icon-rotation-alignment': 'map',
            'icon-overlap': 'always',
            'icon-ignore-placement': true
          }
        });

        playing = true;
        // Restart the animation.
        animate(counter);
      }
    }

    function stop() {
      playing = false;
    }

    function animate() {
      if (!playing) return;
      // Update point geometry to a new position based on counter denoting
      // the index to access the arc.
      point.features[0].geometry.coordinates =
        route.features[0].geometry.coordinates[counter];

      // Calculate the bearing to ensure the icon is rotated to match the route arc
      // The bearing is calculate between the current point and the next point, except
      // at the end of the arc use the previous point and the current point
      try {
        point.features[0].properties.bearing = turf.bearing(
          turf.point(
            route.features[0].geometry.coordinates[
              counter >= steps ? counter - 1 : counter
            ]
          ),
          turf.point(
            route.features[0].geometry.coordinates[
              counter >= steps ? counter : counter + 1
            ]
          )
        );
      } catch (error) {

      }

      // Update the source with this new data.
      map.getSource('point').setData(point);

      // Request the next frame of animation so long the end has not been reached.
      if (counter < steps - 1) {
        requestAnimationFrame(animate);
      }

      counter = counter + 1;

      if (tunnelEntrance(counter)) {
        switchMode('dark');
      } else if (tunnelExit(counter)) {
        switchMode('light');
      }
    }

    document.getElementById('replay').addEventListener('click', function () {
      // Set the coordinates of the original point back to origin
      point.features[0].geometry.coordinates = origin;

      // Update the source layer
      map.getSource('point').setData(point);

      // Reset the counter
      counter = 0;

      // Restart the animation.
      animate(counter);
    });
</script>
</body>
</html>
